Display

1.Screen Type: High-resolution display

2.Screen Size: 7 Inches(17.7cm) diagonally

3.Sweep Speed: 25mm/sec

4.Information: Heart Rate, Lead/pads, A;arm on/off,

SpO2, AED Functions and Prompts, Alarm Selection and Limits, Delivered Energy.

SpO2

1.Measurement Range: 30~100%, ±2% between 80%~90%,

Others ±5%

2.Alarm Range: User set high limit and low limit

3.Alarm Accuracy: ±10% withinsetting values

4.Alarm time Accuracy: less than 12 sec

ECG Monitoring

1.Patient Connection: 3-lead ECG cable, or 5-lead ECG cable, paddles
2.Lead Selection: Displayed on monitor, paddles, I,II,III,AVR,AVL,AVF,V
3.ECG Size: 0.25,0.5,1,1.5.2.4cm/mV display on monitor
4.Heart Rate: 20-300BPM
5.Heart Rate Alarm: On/Off display on monitor, user-selectable
6.Smart Alarms: Beeper/voice prompts indicate shockable rhythm

Recorder

1.Paper: 50mm thermal
2.Speed: 12.5mm/sec,25mm/sec,50mm/sec. User-selectable 6-second delay
3.Printing Method: High-resolution, thermal array print head
4.Print-out Modes: Manual or automatic, user-configurable
On/Off Control: Front panel and paddle
5.Automatic Function: 9-second recording initiated by alarm activation or defibrillator charge or defibrillator discharge

Defibrillator

1.Waveform: Biphasic
2.Energy Display: Monitor display indicates both selected and delivered energy
3.Charge Prompt Type: Voice and visual prompts
4.Electrode Impedance Measurement Range:0-250 ohms

Manual Mode

1.Energy Selection: Selectable at 2,5,7,10,20,30,50,70,100,       150,200,300,360 joules
2.Synchronized Mode: Synchronizes defibrillator pulse to patient's
3.R-wave. "SYNC" message displayed on monitor

Battery

1.Type: Rechargeable, Ni-MH battery,12V
2.Operation Time: For a new, fully charged battery60 defibrillator discharges at maximum energy, or 3 hours minimum of continuous ECG monitoring .                            Additional parameters will effect operation time with different functions.


AED Mode

1. AED Function: Auto analyze and charge ×3 with programmable auto energy level selection, screen prompts, and voice prompts
2. Shockable Rhythms: Ventricular fibrillation, Ventricular tachycardia, QRS complex wave duration
Charge Control: Control on device front panel, press key on paddle
