Your position: Home > Products > 6-Laboratory Products > 6-6 Lab Incubator >
Laboratory Incubator
- TEL：+8618605320580(Whatsapp）
- EMAIL:info@luckmed.com
- Product description: Laboratory Incubator The whole test box is composed of a monolithic assembled welded structure, that is, a test box body and an electronic control part. The test box body part includes a test box working chamber and a retaining structure: a
Product introduction
LABORATORY INCUBATOR
The whole test box is composed of a monolithic assembled welded structure, that is, a test box body and an electronic control part. The test box body part includes a test box working chamber and a retaining structure: a duct system, a heating system, and a forced air cooling system; the electric control system is installed at the top of the test box, and is directly in front of the operator for operation and use.
1. Liner: SUS304 stainless steel plate;
2. the box shell: cold-rolled sheet plastic;
3. Door: single door swing type;
4, thermal insulation: thickness of insulation layer 100 mm, ultra-fine fiberglass cotton;
5. Observation device: one hollow observation window is arranged in the upper part of the door; (please specify when ordering)
6. Internal ventilation: The air blower with a stainless steel shaft drives the blower to achieve forced ventilation through the air duct.
Specification:
| Equipment model | TPY-150P |
| Studio actual (internal work) size | 550 × 500 × 550(mm) |
| Temperature range | RT+10~80°C |
| Temperature uniformity | ≤ ± 2 ° C |
| Temperature fluctuation | ≤ 0.5 ° C |
| Sensor deviation | ≤ 1.2 ° C |
| Heating rate | 0.1 ~ 2.0 ° C / mim |
| Heating time | RT ~ 65 ° C ≤ 20 min |
| Temperature control accuracy | 0.1 ° C |
| Temperature control deviation | ≤ 1.0 ° C |
| The total power | about 1.6KW |
| Noise | ≤ 65dB |
| Wind speed | ≤1.0m / s |
| Equipment control mode | integrated control |
| Sample rack bearing | ≤ 30KG |
| Power | AC220V, 50HZ |
